Flaking Machine

Description & Features

With two rolls relative rotating, the flaking machine which makes the oat, barley, wheat flakes. It is a key machine for cereal flakes processing line. WIth hydraulic control which lead the machine automatically.



1. Square bearing house, stable, reliable and low noise.
2. Easy to adjust flakes thickness, reliable anti-collision function.
3. Centrifugal casting iron rolls keep the stable performance.
4. Hydraulic control system make the pressure between 2 rolls constant automatically.
5. Humanized design, easy operation, stable flakes making, long service life.
6. PLC automatic control is available.



Product Specification

Model	Flakes Thickness	Capacity	Power	Weight	Dimension
YYPY40x100	0.3mm(adjustable)	800kg/h	2x11kw	3500kg	1770x1200x1370mm
YYPY40x125	0.3mm(adjustable)	1200kg/h	2x15kw	4000kg	2020x1200x1370mm
YYPY40x150	0.3mm(adjustable)	1500kg/h	2x18.5kw	4800kg	2270x1200x1370mm
YYPY60x100	0.3mm(adjustable)	2000kg/h	2x22kw	7000kg	1912x1669x1834mm
YYPY60x125	0.3mm(adjustable)	2800kg/h	2x30kw	8000kg	2162x1669x1834mm
YYPY60x150	0.3mm(adjustable)	3600kg/h	2x37kw	9000kg	2412x1669x1834mm
